Air Atomizing Spray Nozzles
Back to No Drip External Mix Atomizing Nozzles In Grade 303 Stainless Steel
No Drip External Mix. Round Pattern. 3.8 GPH / 14.4 LPH Max. 1/4 NPT Female Threads.

Item Code: ER2010SS

No Drip External Mix. Round Pattern. 3.8 GPH / 14.4 LPH Max. 1/4 NPT Female Threads.

Item Code: ER2010SS

No Drip External Mix. Round Pattern. 3.8 GPH / 14.4 LPH Max. 1/4 NPT Female Threads.

1/4 FNPT no drip external mix round pattern nozzles feature their ability to preserve precious liquids and protect product finished from drips. They are great where a high volume of liquid is needed over a specific area or general area, but not in a flat pattern. Applications include spot treatments of parts, covering irregularly shaped objects or covering a container of parts with a heavy coat. They are also an excellent choice for controlling heavy dust and particulates. Since they are external mix, airflow and liquid flow can be controlled independently. For pressure fed applications with independent air and liquid control. Made from 303SS for corrosion resistance. For pressure fed applications with independent air and liquid control.

Connection 1/4" NPT

Performance Figures below

Quick Links

Dispatch by 16/02/26

Max Liquid Consumption: 0-50 LPH

Spray Pattern: Round

Thread Size: 1/4" NPT

£556.40 ea. Excl VAT £667.68 ea. Inc VAT
