Spring Plunger. M4 Thread. 16mm Length. 2.5mm Ball Diameter. 4N Spring Force. Stainless Steel.

Item Code: K0310.404

Spring Plunger. M4 Thread. 16mm Length. 2.5mm Ball Diameter. 4N Spring Force. Stainless Steel.

Item Code: K0310.404

Material:
Sleeve 1.4305.
Ball 1.4034.
Spring 1.4310. Surface finish:
Natural finish.
Ball hardened.

Quick Links

30 in stock

D: M4

L: 16

D1: 2,5

H: 0,8

N: 0,6

Spring strength: standard

Spring force initial pressure F1 approx. N: 4

Spring force final pressure F2 approx. N: 10

£2.90 ea. Excl VAT £3.48 ea. Inc VAT

Qty

Product Wishlist & Compare Placeholder

Qty	Price per item	Savings
50 +	£2.49	14%

Free Standard Delivery over £75 ex VAT

Spend another £75 to qualify

modal placeholder

Quick Links

Material:
Sleeve 1.4305.
Ball 1.4034.
Spring 1.4310. Surface finish:
Natural finish.
Ball hardened.

D	M4
L	16
D1	2,5
H	0,8
N	0,6
Spring strength	standard
Spring force initial pressure F1 approx. N	4
Spring force final pressure F2 approx. N	10
