DISC HANDWHEEL D1=100 REAMED HOLE D2=10H8, SIZE:1, FORM:E, DUROPLAST, COMP:STEEL, WITHOUT GRIP

Item Code: K0165.1100X10

DISC HANDWHEEL D1=100 REAMED HOLE D2=10H8, SIZE:1, FORM:E, DUROPLAST, COMP:STEEL, WITHOUT GRIP

Item Code: K0165.1100X10

DISC HANDWHEEL D1=100 REAMED HOLE D2=10H8, SIZE:1, FORM:E, DUROPLAST, COMP:STEEL, WITHOUT GRIP

Material:
Black duroplastic PF 31;
hub in steel, nickel-plated or stainless steel 1.4305, natural finish Surface finish:
Deburred and high-polish finish

Quick Links

Dispatch by 11/06/25

Form: E

D3: 22

L1: 29.5

L3: 39

D1: 100

H2: 8

L2: 19

D2: 10H8

D4: 20

D8: 29

£16.10 ea. Excl VAT £19.32 ea. Inc VAT

This product is currently out of stock. Your item will be shipped when it is back in stock.

Qty

Product Wishlist & Compare Placeholder

Qty	Price per item	Savings
15 +	£14.81	8%

Free Standard Delivery over £75 ex VAT

Spend another £75 to qualify

modal placeholder

Quick Links

Description

Material:
Black duroplastic PF 31;
hub in steel, nickel-plated or stainless steel 1.4305, natural finish Surface finish:
Deburred and high-polish finish

Product Dimensions

Form	E
D3	22
L1	29.5
L3	39
D1	100
H2	8
L2	19
D2	10H8
D4	20
D8	29

Downloads

STP

DISC HANDWHEEL D1=100 REAMED HOLE D2=10H8, SIZE:1, FORM:E, DUROPLAST, COMP:STEEL, WITHOUT GRIP

DISC HANDWHEEL D1=100 REAMED HOLE D2=10H8, SIZE:1, FORM:E, DUROPLAST, COMP:STEEL, WITHOUT GRIP
