Material:
Grip thermoplastic.
Steel parts stainless steel 1.4305.
Version:
Grip black.
Steel parts bright.
Note:
Ball lock pins are used for quick and easy fastening and joining of parts and workpieces. The two balls are disengaged by pressing the push button and the pin can be slipped into holes in the workpieces. Release the button to lock the balls and secure the connection. An option for connecting a retaining cable is provided.
Shearing force double shear (F) = S · τ aB max.
Accessory:
Safety spiral cable K0367.10200
Retaining cable with loop K0367. .....
Key ring K0367.15/19/23
Bushes for ball lock pins K0724....
